²  Element:  Metal Oxide
²  Coating:  Epoxy Resin
²  Filling: Epoxy Resin
²  Pipe: SUS pipe with black painting
²  Lead wire: Teflon wire
²  Connector: Optional

l  Dissipation Constant: Ta: 25℃ = 1.5 mW/℃
l  Response Time: 2 sec
l  Resistance at 25℃ : 50kΩ
l  Resistance tolerance : ±1%
l  Operating temperature: -30~80℃
l  Application: Temperature indicator
